Key Features: HDMI Matrix Switching: 4 HDMI/Analog sources to 2 HDMI outputs, independent in full-screen and quadrant modes

Seamless Switching: Un-interrupted screen transitions during source selections in full-screen mode or multi-view modes

Resolution Support: Supports SD, HD, and VESA input resolutions up to 1080p / 1920x1200 on HDMI and analog video Inputs

Analog to Digital Video Conversion: Analog video input ports support VGA / DB15 or Component / YPbPr signal types Ultra HD/4K Up-scaling: Outputs independently upscale to Ultra HD/4K in 4K Quadrant mode

Multi-View Window Processing: Create & store custom multi-view layouts, recall custom presets in 1080p

(2K) Multi-View mode Quadrant Mode (4K or 2K): Independent outputs in four equally-sized windows

Multi-View Mode (2K): Linked/mirrored outputs in customized screen layout Image Layering: Stack images with customizable priority settings

Window Transparency and Border: View content through each other and choose window bezel width and coloring

Web Control Interface: Reduces installation time and provides basic and advanced video and audio setup

Audio De-Embed: Audio from the selected input is be de-embedded through the Coax digital (PCM) output in addition to the HDMI output

Independent Video & Audio Matrixing: Listen to any audio source while in quadrant or multi-view modes

Full Buffer System™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, and EDID Control handshake

EDID: Internal library with 5 default EDID configurations for input, in addition to native EDID data for any Output / Display TMDS re-clocking: Support for long HDMI connectivity using Key Digital® HDMI cables

Deep Color Support: Up to 12 bits/color Licensing: Fully licensed and compatible with HDMI up to 4KUHD/60Fps and HDCP 1.0 to HDCP 1.4 technologies. For HDCP 2.2 sources use KD-HDFIX22 in conjunction with this product.

Control: Front panel buttons, Serial IR, Optical IR, RS-232, TCP-IP and Web Control, including discrete power ON/OFF via IR, RS-232, and TCP-IP Control System Support: Compass Control®, AMX®, Control4®, Crestron®, KNX®, RTI®, Savant, URC®, Honeywell®, HAI®, Leviton®, etc

- See more at: http://www.keydigital.com/items.asp?ItemCode=KDMLV4x2&Company=KEY#sthash.jtx5wZEu.dpuf

Use the FLIR FX Sport Housing to turn your FLIR FX wireless HD monitoring camera into an action camera for capture all of your extreme sports and adventures in 1080p30 quality. The tough acrylic shell helps provides added protection for your camera and is waterpoof to depths of 65'. Spring-loaded buttons built into the case let you access all camera buttons and functions and a 1/4"-20 threaded hole lets you mount it on a variety of optional camera mounts and support devices. Included with the Sports Housing is a ball and socket stand, and three 3M adhesive mounts for attaching to boards, helmets, or other surfaces.

FP63A

• Universal design
• VESA compatible
• Portrait orientation
• Low-profile, holds screen close to wall for a clean look
• Open wall plate allows easy access for wiring
• Lateral shift for perfect placement
• Pre-sorted hardware pack for easy installation to wood studs or concrete surfaces included

Please use E-Z mount finder to verify compatibility of your flat panel screen and this mount

TV size range

37” – 63”+

Weight capacity

150lb (68kg)

Max mounting pattern

446x601mm

VESA mounting pattern

75x75mm, 100x100mm, 200x100mm, 200x200mm, 300x200mm, 300x300mm, 400x200mm, 400x300mm, 400x400mm, 200x600mm, 400x600mm

Post-Installation Leveling

+-5º

Depth from wall

1.4” (35.6mm)

Lateral adjustment

varies with screen

Mounting surface

wood stud, concrete, cinder block or metal stud (accessory required HT4)

Stud spacing

dual stud 16”

Construction

high-grade cold rolled steel

Product finish

scratch resistant epoxy powder coat

Product weight

6.8lb (1.3kg)

Package specifications

29”x11”x4”

Color

black

Model number

FP63A

Warranty

10-years



SEVERTSON GE169120 16X9  135" Electric Screen Severtson Matte White •Stylish, white all-aluminum case.
•Multiple control methods.
•Wall or ceiling mounted.
manual button, IR remote, RS-232, and 12v trigger come built-in to every screen,

SEVERTSON GE169120 16X9  135" Electric Screen Severtson Matte White •Stylish, white all-aluminum case.
•Multiple control methods.
•Wall or ceiling mounted.
manual button, IR remote, RS-232, and 12v trigger come built-in to every screen,

MoCA Splitters



This MoCA splitter product line has been carefully designed to
optimize the balance between the traditional performance requirements in the
5-1000 MHz spectrum along with the additional requirements necessary for the
proper communication of the MoCA® signals in the 1125-1675 MHz spectrum.



 PRODUCT FEATURES

• UL Listed
• UL approved PCV 20 year non-fade label
• Die-cast zinc tin plated housing
• Tin plated copper soldered back
• 3-way stainless steel mounting and ground screws
• 360 degree gold plated beryllium copper insert pin
• High-density ferrites
• Layered circuit board technology
• Low isolation at the MoCA frequencies
• Low intermodulation distortion
• 6kV surge protection
• Meets or exceeds all applicable SCTE requirements

 Not all configurations shown - available in Vertical and Horizontal are 2-port, 3-port, 4-port

 Available in Vertical Only, 6-Port and 8-Port

MoCA Splitters



This MoCA splitter product line has been carefully designed to
optimize the balance between the traditional performance requirements in the
5-1000 MHz spectrum along with the additional requirements necessary for the
proper communication of the MoCA® signals in the 1125-1675 MHz spectrum.



 PRODUCT FEATURES

• UL Listed
• UL approved PCV 20 year non-fade label
• Die-cast zinc tin plated housing
• Tin plated copper soldered back
• 3-way stainless steel mounting and ground screws
• 360 degree gold plated beryllium copper insert pin
• High-density ferrites
• Layered circuit board technology
• Low isolation at the MoCA frequencies
• Low intermodulation distortion
• 6kV surge protection
• Meets or exceeds all applicable SCTE requirements

 Not all configurations shown - available in Vertical and Horizontal are 2-port, 3-port, 4-port

 Available in Vertical Only, 6-Port and 8-Port

MoCA Splitters



This MoCA splitter product line has been carefully designed to
optimize the balance between the traditional performance requirements in the
5-1000 MHz spectrum along with the additional requirements necessary for the
proper communication of the MoCA® signals in the 1125-1675 MHz spectrum.



 PRODUCT FEATURES

• UL Listed
• UL approved PCV 20 year non-fade label
• Die-cast zinc tin plated housing
• Tin plated copper soldered back
• 3-way stainless steel mounting and ground screws
• 360 degree gold plated beryllium copper insert pin
• High-density ferrites
• Layered circuit board technology
• Low isolation at the MoCA frequencies
• Low intermodulation distortion
• 6kV surge protection
• Meets or exceeds all applicable SCTE requirements

 Not all configurations shown - available in Vertical and Horizontal are 2-port, 3-port, 4-port

 Available in Vertical Only, 6-Port and 8-Port
